Type N-BH1
90 degree lead support similar to type B2.
Type N-BH2
Single terminal mounted at each end of band near gap. This system is an standard termination system for both large and small one piece bands.
Type N-BH3
Similar to type B2 except the terminal are at the opposite.
Type N-BH4
Threaded post terminals is tandem position is ideal for narrow width heater.
Type N-BH5
Flexible post terminals in parallel position and mounted at one end of piece band near gap.
Type N-BH6
Two terminals at one end of each half of two piece band. Permits all wiring at one location on band. Specify total watts or watts per half, total volts or volts per half.
Type N-BH7
Two piece band with clamping straps. 1” wide heaters will have post terminals located at 90° to gap. Specify total watts or watts per half, total volts or volts per half.
Type N-BH8
2 pin socket mounted to heater for use as quick disconnect system. Please specify socket position
Type N-BH9
Two ways ceramic connector can be supplied for easy connection. Available up to 30 amps.
