NTT Silica Quartz Infrared Heater

Overview
NTT Silica Quartz Heater are one of the MOST EFFICIENT sources of radiant energy.

General Description

• Quartz heaters can deliver near and far infrared wavelengths, which is more effective than a single wavelength, capable of generating full heat output capacity in 40 to 50 seconds and cool down in less than 15 seconds.
• They offer excellent life characteristics whether operated continuously or intermittently with a quick heat and cool down response time.
• For most efficient heating and longer operating life, quartz heating applications should be rated around 35 to 40 watts per square inch.
• Quartz Heaters consist of a helically wound resistance coil housed in a pure vitreous silica fused quartz tube. The heating coil is specially designed to provide long life at rated voltage. The quartz tubing is fastened with specially designed ceramic insulating caps for power connecting termination.
• Quartz heating elements do not give off an objectionable glare because of a very low emission in the visible spectrum. Optimum design provides a clear red color on the translucent quartz tube when operating at full voltage, providing an infrared wavelength at energy peak of 2.5 to 3.0 microns.

Important Note
ALL Silica Quartz Infrared Heater is designed for Horizontal Mounting usage only.
